800-10-026-30-480101

Preci-Dip
In Stock: 141

Can ship immediately

Pricing:
  • 1$2.9428
  • 200$2.57045

Quote It

Technical Details

  • Series:800
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:26
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board
  • Shrouding:Unshrouded
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.141" (3.60mm)



  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.110" (2.79mm)
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Gold
  • Contact Material:Brass
  • Insulation Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
  • Features:-
  • Operating Temperature:-55°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:150VDC

Related Products


4-647075-0

CONN HEADER VERT 10POS 2.54MM

4-647075-0 Datasheet
  • 1: $2.94294
  • 500: $2.54800

1473898-1

CONN HEADER VERT 12POS 2.2MM

1473898-1 Datasheet
  • 1: $2.94300
  • 3456: $2.79450

0702800747

CONN HEADER VERT 78POS 2.54MM

0702800747 Datasheet
  • 1: $2.94307
  • 1000: $2.94307

957244-5002-AR

CONN HEADER R/A 44POS 2MM

957244-5002-AR Datasheet
  • 1: $2.94320
  • 8000: $2.94320

1888871-1

CONN HEADER R/A 30POS 2.54MM

1888871-1 Datasheet
  • 1: $2.94366
  • 500: $2.90374

1888870-1

CONN HEADER VERT 30POS 2.54MM

1888870-1 Datasheet
  • 1: $2.94367
  • 700: $2.90373

4-2842280-2

42P,2MM,SHRD HDR,DRVT,SMD,0.76AU

  • 1: $2.94397

830-80-038-10-001101

CONN HEADER VERT 38POS 2MM

830-80-038-10-001101 Datasheet
  • 1: $2.94400
  • 190: $2.71126

892-80-074-10-003101
