0705450082

Woodhead - Molex
In Stock: 107

Can ship immediately

Pricing:
  • 1$2.97728
  • 1,248$2.97728

Quote It

Technical Details

  • Series:SL 70545
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:13
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:0.240" (6.10mm)



  • Contact Length - Post:0.130" (3.30mm)
  • Overall Contact Length:0.470" (11.94mm)
  • Insulation Height:0.465" (11.80mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyester, Glass Filled
  • Features:Board Guide
  • Operating Temperature:-40°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:250V

Related Products


207119-9

CONN HEADER VERT 4POS 4.98MM

207119-9 Datasheet
  • 1: $2.97756
  • 1800: $2.69893

69155-314LF

CONN HEADER R/A 14POS 2.54MM

69155-314LF Datasheet
  • 1: $2.97783
  • 2400: $2.97783

SBH31-NBPB-D32-RA-BK

CONN HEADER R/A 64POS 1.27MM

SBH31-NBPB-D32-RA-BK Datasheet
  • 1: $2.97801
  • 1000: $ 2.97801

SBH31-NBPB-D32-SM-BK

CONN HEADER SMD 64POS 1.27MM

SBH31-NBPB-D32-SM-BK Datasheet
  • 1: $2.97801
  • 1000: $ 2.97801

SBH31-NBPB-D32-SP-BK

CONN HEADER SMD 64POS 1.27MM

SBH31-NBPB-D32-SP-BK Datasheet
  • 1: $2.97801
  • 1000: $ 2.97801

0702871092

CONN HEADER VERT 90POS 2.54MM

0702871092 Datasheet
  • 1: $2.97816
  • 1000: $2.97816

0702871135

CONN HEADER VERT 78POS 2.54MM

0702871135 Datasheet
  • 1: $2.97816
  • 1000: $2.97816

1054059606

NANO FIT SMT R/A HDR 2X3 NAT 15U

  • 1: $2.97845

0740990623
