0440671602

Woodhead - Molex
In Stock: 199

Can ship immediately

Pricing:
  • 1$3.02365
  • 792$2.67809

Quote It

Technical Details

  • Series:Micro-Fit 3.0 44067
  • Package:Tray
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.118" (3.00mm)
  • Number of Positions:16
  • Number of Rows:2
  • Row Spacing - Mating:0.118" (3.00mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Kinked Pin, Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-



  • Contact Length - Post:0.158" (4.01mm)
  • Overall Contact Length:-
  • Insulation Height:0.390" (9.91mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
  • Features:Board Guide
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-

Related Products


SMH100-LPSE-S26-ST-BK

CONN HEADER VERT 26POS 1MM

SMH100-LPSE-S26-ST-BK Datasheet
  • 1: $3.02369
  • 1000: $ 3.02369

892-80-076-10-003101

CONN HEADER VERT 76POS 2.54MM

892-80-076-10-003101 Datasheet
  • 1: $3.02379
  • 190: $2.78479

M80-8541642

CONN HEADER VERT 16POS 2MM

M80-8541642 Datasheet
  • 1: $3.02399
  • 143: $2.88000

800-10-025-20-001101

CONN HEADER R/A 25POS 2.54MM

800-10-025-20-001101 Datasheet
  • 1: $3.02400
  • 200: $2.64115

A1-24PA-2.54DS(71)

CONN HEADER R/A 24POS 2.54MM

A1-24PA-2.54DS(71) Datasheet
  • 1: $3.02400

HIF6B-32PA-1.27DSA(71)

CONN HEADER VERT 32POS 1.27MM

HIF6B-32PA-1.27DSA(71) Datasheet
  • 1: $3.02400

HIF6B-34PA-1.27DS(71)

CONN HEADER R/A 34POS 1.27MM

HIF6B-34PA-1.27DS(71) Datasheet
  • 1: $3.02400

882-70-078-10-001101
