0878314820

Woodhead - Molex
In Stock: 112

Can ship immediately

Pricing:
  • 1$3.0292
  • 1,000$3.0292

Quote It

Technical Details

  • Series:Milli-Grid 87831
  • Package:Tube
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Positions:48
  • Number of Rows:2
  • Row Spacing - Mating:0.079" (2.00mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Length - Mating:0.141" (3.60mm)



  • Contact Length - Post:0.098" (2.50mm)
  • Overall Contact Length:-
  • Insulation Height:0.252" (6.40mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Contact Finish - Post:Tin
  • Contact Material:Phosphor Bronze
  • Insulation Material:Polyamide (PA), Nylon, Glass Filled
  • Features:Keying Slot
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):2A
  • Voltage Rating:125V

Related Products


1054312406

NANO-FIT HDR SMT VT SGL 6CKT 30A

  • 1: $3.02925

0741622310

CONN HEADER R/A 10POS 2.54MM

0741622310 Datasheet
  • 1: $3.02934
  • 1458: $3.02934

800-10-034-40-001101

CONN HEADER SMD R/A 34POS 2.54MM

800-10-034-40-001101 Datasheet
  • 1: $3.02942
  • 150: $3.02942

800-80-043-40-001101

CONN HEADER SMD R/A 43POS 2.54MM

800-80-043-40-001101 Datasheet
  • 1: $3.02943
  • 300: $2.78980

800-80-043-20-001101

CONN HEADER R/A 43POS 2.54MM

800-80-043-20-001101 Datasheet
  • 1: $3.02944
  • 250: $2.78980

5-103166-8

CONN HEADER R/A 20POS 2.54MM

5-103166-8 Datasheet
  • 1: $3.02973
  • 1232: $2.76002

75160-129-27LF

CONN HEADER VERT 27POS 2.54MM

75160-129-27LF Datasheet
  • 1: $3.02974
  • 500: $2.80143

HIF3H-12PB-2.54DSA(71)

CONN HEADER VERT 12POS 2.54MM

HIF3H-12PB-2.54DSA(71) Datasheet
  • 1: $3.03000
  • 10: $2.90880
  • 225: $2.42400

4-102977-0-13

CONN HEADER VERT 26POS 2.54MM

4-102977-0-13 Datasheet
  • 1: $3.03000
  • 10: $2.91096
  • 25: $2.66856

4-103322-0-27
