0348300802
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 8POS 3.5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0348300802 Datasheet
-
ECAD Model
- Share
In Stock: 149
Can ship immediately
Pricing:
- 1$3.4356
- 420$3.4356
Quote It
Technical Details
- Series:MX150 34830
- Package:Tray
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Blade
- Pitch - Mating:0.138" (3.50mm)
- Number of Positions:8
- Number of Rows:2
- Row Spacing - Mating:0.138" (3.50mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:1.014" (25.75mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Board Guide
- Operating Temperature:-40°C ~ 125°C
- Ingress Protection:IP67/IP69K - Dust Tight, Water Resistant, Waterproof
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):-
- Voltage Rating:14VDC
