966140-1

Technical Details

• Series:Junior Power Timer
• Package:Tray
• Part Status:Active
• Connector Type:Header
• Contact Type:Tab
• Pitch - Mating:0.197" (5.00mm)
• Number of Positions:18
• Number of Rows:3
• Row Spacing - Mating:0.217" (5.51mm)
• Number of Positions Loaded:All
• Style:Board to Board or Cable
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.118" (3.00mm)
• Overall Contact Length:-
• Insulation Height:1.012" (25.70mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Copper Alloy
• Insulation Material:Polyamide (PA66), Nylon 6/6, Glass Filled
• Features:Mounting Flange
• Operating Temperature:-30°C ~ 100°C
• Ingress Protection:-
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):-
• Voltage Rating:28VDC
