0194280001

Technical Details

• Series:MX150L 19428
• Package:Tray
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Blade
• Pitch - Mating:0.230" (5.84mm)
• Number of Positions:12
• Number of Rows:2
• Row Spacing - Mating:0.236" (6.00mm)
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Panel Mount, Through Hole
• Termination:Solder
• Fastening Type:Locking Ramp
• Contact Length - Mating:-

• Contact Length - Post:0.130" (3.30mm)
• Overall Contact Length:-
• Insulation Height:1.562" (39.66mm)
• Contact Shape:Square
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:100.0µin (2.54µm)
• Contact Finish - Post:Tin
• Contact Material:Copper Alloy
• Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
• Features:Mounting Flange
• Operating Temperature:-
• Ingress Protection:IP67 - Dust Tight, Waterproof
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black
• Current Rating (Amps):-
• Voltage Rating:-
