1-2271457-8

Technical Details

• Series:-
• Package:Tray
• Part Status:Active
• Connector Type:Header
• Contact Type:Tab
• Pitch - Mating:0.295" (7.50mm)
• Number of Positions:8
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Board or Cable
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.150" (3.81mm)
• Overall Contact Length:-
• Insulation Height:0.472" (12.00mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Copper Alloy
• Insulation Material:Thermoplastic, Polyester, Glass Filled
• Features:Board Lock
• Operating Temperature:-30°C ~ 105°C
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black
• Current Rating (Amps):14.5A
• Voltage Rating:600VAC
