207441-8

Technical Details

• Series:Metrimate
• Package:Tray
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.197" (5.00mm)
• Number of Positions:9
• Number of Rows:3
• Row Spacing - Mating:0.197" (5.00mm)
• Number of Positions Loaded:All
• Style:Board to Board or Cable
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Latch Lock
• Contact Length - Mating:-

• Contact Length - Post:0.181" (4.60mm)
• Overall Contact Length:-
• Insulation Height:0.464" (11.79mm)
• Contact Shape:Circular
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:150.0µin (3.81µm)
• Contact Finish - Post:Tin
• Contact Material:Brass
• Insulation Material:Polyamide (PA), Nylon
• Features:-
• Operating Temperature:-55°C ~ 130°C
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black, Red
• Current Rating (Amps):7.5A
• Voltage Rating:600V
