CWN-370-50-0021

Technical Details

• Series:CWN
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.100" (2.54mm)
• Number of Positions:50
• Number of Rows:2
• Row Spacing - Mating:0.100" (2.54mm)
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole
• Termination:Wire Wrap
• Fastening Type:Push-Pull
• Contact Length - Mating:0.240" (6.10mm)

• Contact Length - Post:0.610" (15.49mm)
• Overall Contact Length:-
• Insulation Height:0.681" (17.30mm)
• Contact Shape:Circular
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:30.0µin (0.76µm)
• Contact Finish - Post:Nickel
• Contact Material:Phosphor Bronze
• Insulation Material:Thermoplastic
• Features:Keying Slot, Mounting Flange
• Operating Temperature:-55°C ~ 125°C
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Blue
• Current Rating (Amps):1A
• Voltage Rating:-
