DT15-08PB

Technical Details

• Series:DT
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:-
• Number of Positions:8
• Number of Rows:2
• Row Spacing - Mating:0.360" (9.14mm)
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Panel Mount, Through Hole
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.122" (3.10mm)
• Overall Contact Length:-
• Insulation Height:1.185" (30.10mm)
• Contact Shape:Circular
• Contact Finish - Mating:-
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:-
• Contact Material:-
• Insulation Material:Plastic
• Features:Mounting Flange
• Operating Temperature:-55°C ~ 125°C
• Ingress Protection:IP68/IP6K9K
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):-
• Voltage Rating:250VDC
