0439151418

Technical Details

• Series:Mini-Fit Sr 43915
• Package:Tray
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.394" (10.00mm)
• Number of Positions:10
• Number of Rows:2
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.327" (8.30mm)
• Overall Contact Length:-
• Insulation Height:0.827" (21.00mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Silver
• Contact Finish Thickness - Mating:100.0µin (2.54µm)
• Contact Finish - Post:Tin
• Contact Material:Copper Zirconium Alloy
• Insulation Material:Polyamide (PA46), Nylon 4/6, Glass Filled
• Features:Board Guide, Board Lock
• Operating Temperature:-
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black
• Current Rating (Amps):-
• Voltage Rating:-
