MX23A18NF3

Technical Details

• Series:MX23A
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.098" (2.50mm)
• Number of Positions:18
• Number of Rows:2
• Row Spacing - Mating:0.173" (4.40mm)
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:-

• Contact Length - Post:0.122" (3.10mm)
• Overall Contact Length:-
• Insulation Height:0.720" (18.30mm)
• Contact Shape:Square
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Brass
• Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
• Features:Mounting Flange
• Operating Temperature:-40°C ~ 125°C
• Ingress Protection:Waterproof
• Material Flammability Rating:-
• Insulation Color:Black
• Current Rating (Amps):3A
• Voltage Rating:-
