5-1418363-3
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 39POS 5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 5-1418363-3 Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$13.18965
- 2,256$13.18965
Quote It
Technical Details
- Series:LEAVYSEAL
- Package:Tray
- Part Status:Active
- Connector Type:Plug
- Contact Type:Tab
- Pitch - Mating:0.197" (5.00mm)
- Number of Positions:39
- Number of Rows:3
- Row Spacing - Mating:0.217" (5.51mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Panel Mount, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:-
- Contact Length - Mating:0.291" (7.40mm)
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:-
- Contact Shape:Rectangular
- Contact Finish - Mating:Silver
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Silver
- Contact Material:Bronze
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Sealed
- Operating Temperature:-40°C ~ 140°C
- Ingress Protection:IP67
- Material Flammability Rating:UL94 HB
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:42V
