TST24RB01Z
VEAM- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 24POS 5.08MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet TST24RB01Z Datasheet
-
ECAD Model
- Share
In Stock: 113
Can ship immediately
Pricing:
- 1$13.905
- 100$12.9
Quote It
Technical Details
- Series:Trident Rectangular
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Male Pin
- Pitch - Mating:0.200" (5.08mm)
- Number of Positions:24
- Number of Rows:4
- Row Spacing - Mating:0.200" (5.08mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Unshrouded
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Holder
- Contact Length - Mating:-
- Contact Length - Post:0.224" (5.70mm)
- Overall Contact Length:-
- Insulation Height:0.531" (13.50mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:Flash
- Contact Finish - Post:-
- Contact Material:-
- Insulation Material:Polyamide (PA), Nylon
- Features:Mounting Flange
- Operating Temperature:-40°C ~ 105°C
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):13A
- Voltage Rating:250V
