1415500000

Technical Details

• Series:Omnimate RSV
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.197" (5.00mm)
• Number of Positions:9
• Number of Rows:3
• Row Spacing - Mating:0.197" (5.00mm)
• Number of Positions Loaded:All
• Style:Board to Board or Cable
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Latch Lock
• Contact Length - Mating:-

• Contact Length - Post:0.177" (4.50mm)
• Overall Contact Length:-
• Insulation Height:0.465" (11.80mm)
• Contact Shape:Circular
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Copper Alloy
• Insulation Material:Polyamide (PA), Nylon
• Features:-
• Operating Temperature:100°C
• Ingress Protection:IP20
• Material Flammability Rating:UL94 V-0
• Insulation Color:Gray
• Current Rating (Amps):10A
• Voltage Rating:300V
