1445900000
Weidmuller- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 24POS 5MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 1445900000 Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
- 1$26.6385
- 20$25.452
Quote It
Technical Details
- Series:Omnimate RSV
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.197" (5.00mm)
- Number of Positions:24
- Number of Rows:4
- Row Spacing - Mating:0.197" (5.00mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:-
- Contact Length - Post:0.126" (3.20mm)
- Overall Contact Length:-
- Insulation Height:0.465" (11.80mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polyamide (PA), Nylon
- Features:Mounting Flange
- Operating Temperature:100°C
- Ingress Protection:IP20
- Material Flammability Rating:UL94 V-0
- Insulation Color:Gray
- Current Rating (Amps):10A
- Voltage Rating:300V
