MTB1-7PAL1-2
VEAM- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 7POS 1.27MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MTB1-7PAL1-2 Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$40.6408
- 25$38.79962
Quote It
Technical Details
- Series:MTB
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:0.050" (1.27mm)
- Number of Positions:7
- Number of Rows:1
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Unshrouded
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Length - Mating:-
- Contact Length - Post:-
- Overall Contact Length:-
- Insulation Height:0.100" (2.54mm)
- Contact Shape:Circular
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:50.0µin (1.27µm)
- Contact Finish - Post:-
- Contact Material:Copper Alloy
- Insulation Material:Diallyl Phthalate (DAP)
- Features:-
- Operating Temperature:-55°C ~ 150°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:-
- Current Rating (Amps):3A
- Voltage Rating:-
