MTB1-10PAL1-01

Technical Details

• Series:MTB
• Package:Bulk
• Part Status:Active
• Connector Type:Header
• Contact Type:Male Pin
• Pitch - Mating:0.050" (1.27mm)
• Number of Positions:10
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Unshrouded
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Push-Pull
• Contact Length - Mating:-

• Contact Length - Post:-
• Overall Contact Length:-
• Insulation Height:0.100" (2.54mm)
• Contact Shape:Circular
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:50.0µin (1.27µm)
• Contact Finish - Post:-
• Contact Material:Copper Alloy
• Insulation Material:Diallyl Phthalate (DAP)
• Features:Guide Pin
• Operating Temperature:-55°C ~ 150°C
• Ingress Protection:-
• Material Flammability Rating:-
• Insulation Color:-
• Current Rating (Amps):3A
• Voltage Rating:-
