In Stock: 182

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:5
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.318" (8.08mm)



  • Contact Length - Post:0.320" (8.13mm)
  • Overall Contact Length:0.738" (18.75mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PTC04SFCN

CONN HEADER VERT 4POS 2.54MM

PTC04SFCN Datasheet

Call for price


PTC03SFCN

CONN HEADER VERT 3POS 2.54MM

PTC03SFCN Datasheet

Call for price


PTC02SFCN

CONN HEADER VERT 2POS 2.54MM

PTC02SFCN Datasheet

Call for price


PTC36SFDN

CONN HEADER VERT 36POS 2.54MM

PTC36SFDN Datasheet

Call for price


PTC35SFDN

CONN HEADER VERT 35POS 2.54MM

PTC35SFDN Datasheet

Call for price


PTC34SFDN

CONN HEADER VERT 34POS 2.54MM

PTC34SFDN Datasheet

Call for price


PTC33SFDN

CONN HEADER VERT 33POS 2.54MM

PTC33SFDN Datasheet

Call for price


PTC32SFDN

CONN HEADER VERT 32POS 2.54MM

PTC32SFDN Datasheet

Call for price


PTC31SFDN

CONN HEADER VERT 31POS 2.54MM

PTC31SFDN Datasheet

Call for price


PTC30SFDN
