In Stock: 168

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:16
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.318" (8.08mm)



  • Contact Length - Post:0.520" (13.21mm)
  • Overall Contact Length:0.938" (23.83mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PTC15SFEN

CONN HEADER VERT 15POS 2.54MM

PTC15SFEN Datasheet

Call for price


PTC14SFEN

CONN HEADER VERT 14POS 2.54MM

PTC14SFEN Datasheet

Call for price


PTC13SFEN

CONN HEADER VERT 13POS 2.54MM

PTC13SFEN Datasheet

Call for price


PTC12SFEN

CONN HEADER VERT 12POS 2.54MM

PTC12SFEN Datasheet

Call for price


PTC11SFEN

CONN HEADER VERT 11POS 2.54MM

PTC11SFEN Datasheet

Call for price


PTC10SFEN

CONN HEADER VERT 10POS 2.54MM

PTC10SFEN Datasheet

Call for price


PTC09SFEN

CONN HEADER VERT 9POS 2.54MM

PTC09SFEN Datasheet

Call for price


PTC08SFEN

CONN HEADER VERT 8POS 2.54MM

PTC08SFEN Datasheet

Call for price


PTC07SFEN

CONN HEADER VERT 7POS 2.54MM

PTC07SFEN Datasheet

Call for price


PTC06SFEN
