In Stock: 104

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:9
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.120" (3.05mm)
  • Overall Contact Length:0.450" (11.43mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC08SAAN

CONN HEADER VERT 8POS 2.54MM

PZC08SAAN Datasheet

Call for price


PZC07SAAN

CONN HEADER VERT 7POS 2.54MM

PZC07SAAN Datasheet

Call for price


PZC06SAAN

CONN HEADER VERT 6POS 2.54MM

PZC06SAAN Datasheet

Call for price


PZC05SAAN

CONN HEADER VERT 5POS 2.54MM

PZC05SAAN Datasheet

Call for price


PZC04SAAN

CONN HEADER VERT 4POS 2.54MM

PZC04SAAN Datasheet

Call for price


PZC03SAAN

CONN HEADER VERT 3POS 2.54MM

PZC03SAAN Datasheet

Call for price


PZC02SAAN

CONN HEADER VERT 2POS 2.54MM

PZC02SAAN Datasheet

Call for price


PZC36SABN

CONN HEADER VERT 36POS 2.54MM

PZC36SABN Datasheet

Call for price


PZC35SABN

CONN HEADER VERT 35POS 2.54MM

PZC35SABN Datasheet

Call for price


PZC34SABN
