In Stock: 130

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:29
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.320" (8.13mm)
  • Overall Contact Length:0.650" (16.51mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC28SACN

CONN HEADER VERT 28POS 2.54MM

PZC28SACN Datasheet

Call for price


PZC27SACN

CONN HEADER VERT 27POS 2.54MM

PZC27SACN Datasheet

Call for price


PZC26SACN

CONN HEADER VERT 26POS 2.54MM

PZC26SACN Datasheet

Call for price


PZC25SACN

CONN HEADER VERT 25POS 2.54MM

PZC25SACN Datasheet

Call for price


PZC24SACN

CONN HEADER VERT 24POS 2.54MM

PZC24SACN Datasheet

Call for price


PZC23SACN

CONN HEADER VERT 23POS 2.54MM

PZC23SACN Datasheet

Call for price


PZC22SACN

CONN HEADER VERT 22POS 2.54MM

PZC22SACN Datasheet

Call for price


PZC21SACN

CONN HEADER VERT 21POS 2.54MM

PZC21SACN Datasheet

Call for price


PZC20SACN

CONN HEADER VERT 20POS 2.54MM

PZC20SACN Datasheet

Call for price


PZC19SACN
