In Stock: 154

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:5
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.230" (5.84mm)
  • Overall Contact Length:0.560" (14.22mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC04SABN

CONN HEADER VERT 4POS 2.54MM

PZC04SABN Datasheet

Call for price


PZC03SABN

CONN HEADER VERT 3POS 2.54MM

PZC03SABN Datasheet

Call for price


PZC02SABN

CONN HEADER VERT 2POS 2.54MM

PZC02SABN Datasheet

Call for price


PZC36SAFN

CONN HEADER VERT 36POS 2.54MM

PZC36SAFN Datasheet

Call for price


PZC35SAFN

CONN HEADER VERT 35POS 2.54MM

PZC35SAFN Datasheet

Call for price


PZC34SAFN

CONN HEADER VERT 34POS 2.54MM

PZC34SAFN Datasheet

Call for price


PZC33SAFN

CONN HEADER VERT 33POS 2.54MM

PZC33SAFN Datasheet

Call for price


PZC32SAFN

CONN HEADER VERT 32POS 2.54MM

PZC32SAFN Datasheet

Call for price


PZC31SAFN
