In Stock: 125

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:2
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.620" (15.75mm)
  • Overall Contact Length:0.950" (24.13mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC36SAGN

CONN HEADER VERT 36POS 2.54MM

PZC36SAGN Datasheet

Call for price


PZC35SAGN

CONN HEADER VERT 35POS 2.54MM

PZC35SAGN Datasheet

Call for price


PZC34SAGN

CONN HEADER VERT 34POS 2.54MM

PZC34SAGN Datasheet

Call for price


PZC33SAGN

CONN HEADER VERT 33POS 2.54MM

PZC33SAGN Datasheet

Call for price


PZC32SAGN

CONN HEADER VERT 32POS 2.54MM

PZC32SAGN Datasheet

Call for price


PZC31SAGN

CONN HEADER VERT 31POS 2.54MM

PZC31SAGN Datasheet

Call for price


PZC30SAGN

CONN HEADER VERT 30POS 2.54MM

PZC30SAGN Datasheet

Call for price


PZC29SAGN

CONN HEADER VERT 29POS 2.54MM

PZC29SAGN Datasheet

Call for price


PZC28SAGN
