In Stock: 124

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:22
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.318" (8.08mm)



  • Contact Length - Post:0.320" (8.13mm)
  • Overall Contact Length:0.738" (18.75mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC21SFCN

CONN HEADER VERT 21POS 2.54MM

PZC21SFCN Datasheet

Call for price


PZC26SFBN

CONN HEADER VERT 26POS 2.54MM

PZC26SFBN Datasheet

Call for price


PZC20SFCN

CONN HEADER VERT 20POS 2.54MM

PZC20SFCN Datasheet

Call for price


PZC19SFCN

CONN HEADER VERT 19POS 2.54MM

PZC19SFCN Datasheet

Call for price


PZC18SFCN

CONN HEADER VERT 18POS 2.54MM

PZC18SFCN Datasheet

Call for price


PZC25SFBN

CONN HEADER VERT 25POS 2.54MM

PZC25SFBN Datasheet

Call for price


PZC17SFCN

CONN HEADER VERT 17POS 2.54MM

PZC17SFCN Datasheet

Call for price


PZC16SFCN

CONN HEADER VERT 16POS 2.54MM

PZC16SFCN Datasheet

Call for price


PZC15SFCN
