In Stock: 191

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:52
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.230" (5.84mm)



  • Contact Length - Post:0.520" (13.21mm)
  • Overall Contact Length:0.850" (21.59mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PTC25DAEN

CONN HEADER VERT 50POS 2.54MM

PTC25DAEN Datasheet

Call for price


PTC24DAEN

CONN HEADER VERT 48POS 2.54MM

PTC24DAEN Datasheet

Call for price


PTC23DAEN

CONN HEADER VERT 46POS 2.54MM

PTC23DAEN Datasheet

Call for price


PTC22DAEN

CONN HEADER VERT 44POS 2.54MM

PTC22DAEN Datasheet

Call for price


PTC21DAEN

CONN HEADER VERT 42POS 2.54MM

PTC21DAEN Datasheet

Call for price


PTC20DAEN

CONN HEADER VERT 40POS 2.54MM

PTC20DAEN Datasheet

Call for price


PTC19DAEN

CONN HEADER VERT 38POS 2.54MM

PTC19DAEN Datasheet

Call for price


PTC18DAEN

CONN HEADER VERT 36POS 2.54MM

PTC18DAEN Datasheet

Call for price


PTC17DAEN

CONN HEADER VERT 34POS 2.54MM

PTC17DAEN Datasheet

Call for price


PTC16DAEN
