In Stock: 173

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:48
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.318" (8.08mm)



  • Contact Length - Post:0.120" (3.05mm)
  • Overall Contact Length:0.538" (13.67mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PTC23DFAN

CONN HEADER VERT 46POS 2.54MM

PTC23DFAN Datasheet

Call for price


PTC22DFAN

CONN HEADER VERT 44POS 2.54MM

PTC22DFAN Datasheet

Call for price


PTC21DFAN

CONN HEADER VERT 42POS 2.54MM

PTC21DFAN Datasheet

Call for price


PTC20DFAN

CONN HEADER VERT 40POS 2.54MM

PTC20DFAN Datasheet

Call for price


PTC19DFAN

CONN HEADER VERT 38POS 2.54MM

PTC19DFAN Datasheet

Call for price


PTC18DFAN

CONN HEADER VERT 36POS 2.54MM

PTC18DFAN Datasheet

Call for price


PTC17DFAN

CONN HEADER VERT 34POS 2.54MM

PTC17DFAN Datasheet

Call for price


PTC16DFAN

CONN HEADER VERT 32POS 2.54MM

PTC16DFAN Datasheet

Call for price


PTC15DFAN

CONN HEADER VERT 30POS 2.54MM

PTC15DFAN Datasheet

Call for price


PTC14DFAN
