In Stock: 185

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:-
  • Package:Bulk
  • Part Status:Obsolete
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Positions:18
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Number of Positions Loaded:All
  • Style:Board to Board or Cable
  • Shrouding:Unshrouded
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Length - Mating:0.318" (8.08mm)



  • Contact Length - Post:0.420" (10.67mm)
  • Overall Contact Length:0.838" (21.29mm)
  • Insulation Height:0.100" (2.54mm)
  • Contact Shape:Square
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:10.0µin (0.25µm)
  • Contact Finish - Post:Tin
  • Contact Material:Copper Alloy
  • Insulation Material:Thermoplastic, Polyester
  • Features:-
  • Operating Temperature:-
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):3A
  • Voltage Rating:-

Related Products


PZC08DFDN

CONN HEADER VERT 16POS 2.54MM

PZC08DFDN Datasheet

Call for price


PZC07DFDN

CONN HEADER VERT 14POS 2.54MM

PZC07DFDN Datasheet

Call for price


PZC06DFDN

CONN HEADER VERT 12POS 2.54MM

PZC06DFDN Datasheet

Call for price


PZC05DFDN

CONN HEADER VERT 10POS 2.54MM

PZC05DFDN Datasheet

Call for price


PZC04DFDN

CONN HEADER VERT 8POS 2.54MM

PZC04DFDN Datasheet

Call for price


PZC03DFDN

CONN HEADER VERT 6POS 2.54MM

PZC03DFDN Datasheet

Call for price


PZC02DFDN

CONN HEADER VERT 4POS 2.54MM

PZC02DFDN Datasheet

Call for price


PZC36DFEN

CONN HEADER VERT 72POS 2.54MM

PZC36DFEN Datasheet

Call for price


PZC35DFEN
