MX7-93PL-C4
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 93POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet MX7-93PL-C4 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:MX7
- Package:Bulk
- Part Status:Obsolete
- Connector Type:Header
- Contact Type:Male Pin
- Pitch - Mating:-
- Number of Positions:93 (75 + 18 Power)
- Number of Rows:-
- Row Spacing - Mating:-
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:-
- Contact Length - Post:0.157" (4.00mm)
- Overall Contact Length:-
- Insulation Height:0.874" (22.20mm)
- Contact Shape:Square
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:Copper Alloy
- Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
- Features:Mounting Flange
- Operating Temperature:-40°C ~ 85°C
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):5A, 7A
- Voltage Rating:-
