0010181065
Woodhead - Molex
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER VERT 6POS 5.03MM
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 0010181065 Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:3099
- Package:Bulk
- Part Status:Obsolete
- Connector Type:Header
- Contact Type:Female Socket; Male Pin
- Pitch - Mating:0.198" (5.03mm)
- Number of Positions:6
- Number of Rows:2
- Row Spacing - Mating:0.198" (5.03mm)
- Number of Positions Loaded:All
- Style:Board to Board or Cable
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Latch Lock
- Contact Length - Mating:-
- Contact Length - Post:0.170" (4.32mm)
- Overall Contact Length:-
- Insulation Height:0.421" (10.70mm)
- Contact Shape:Circular
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:Tin
- Contact Material:-
- Insulation Material:Polyester
- Features:Board Guide
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:UL94 V-0
- Insulation Color:Black
- Current Rating (Amps):-
- Voltage Rating:-
