9-178764-6
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HEADER R/A 64POS
- CategoryRectangular Connectors - Headers, Male Pins
- Datasheet 9-178764-6 Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:Multi-Lock
- Package:Tube
- Part Status:Obsolete
- Connector Type:-
- Contact Type:Tab
- Pitch - Mating:-
- Number of Positions:64
- Number of Rows:2
- Row Spacing - Mating:0.205" (5.20mm)
- Number of Positions Loaded:All
- Style:Board to Cable/Wire
- Shrouding:Shrouded - 4 Wall
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Length - Mating:0.280" (7.11mm)
- Contact Length - Post:0.157" (4.00mm)
- Overall Contact Length:-
- Insulation Height:0.862" (21.89mm)
- Contact Shape:Rectangular
- Contact Finish - Mating:-
- Contact Finish Thickness - Mating:-
- Contact Finish - Post:-
- Contact Material:Brass
- Insulation Material:Polybutylene Terephthalate (PBT)
- Features:Mounting Flange
- Operating Temperature:-
- Ingress Protection:-
- Material Flammability Rating:-
- Insulation Color:Gray
- Current Rating (Amps):Varies by Wire Gauge
- Voltage Rating:-
