HJ1S050HA1R6000
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 50P 0.016 GOLD SMD R/A
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet HJ1S050HA1R6000 Datasheet
-
ECAD Model
- Share
In Stock: 140
Can ship immediately
Pricing:
- 1$1.3936
- 6,000$1.3936
Quote It
Technical Details
- Series:HJ1
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Outer Shroud Contact
- Style:Board to Cable/Wire
- Number of Positions:50
- Number of Positions Loaded:All
- Pitch - Mating:0.016" (0.40mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Surface Mount, Right Angle
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Insulation Color:Black
- Insulation Height:0.035" (0.90mm)
- Contact Length - Post:-
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:-
- Contact Finish - Post:Gold
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:Shielded, Solder Retention
- Current Rating (Amps):1A per Contact
- Voltage Rating:100V
