IL-WX-20SB-VF-A1-B-E1000E
JAE Electronics- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 20POS 0.031 GOLD SMD
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet IL-WX-20SB-VF-A1-B-E1000E Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$1.4138
- 1,000$1.4138
Quote It
Technical Details
- Series:IL-WX
- Package:Tape & Reel (TR)
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Forked
- Style:Board to Board
- Number of Positions:20
- Number of Positions Loaded:All
- Pitch - Mating:0.031" (0.80mm)
- Number of Rows:2
- Row Spacing - Mating:0.059" (1.50mm)
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:-
- Insulation Color:Black
- Insulation Height:0.128" (3.25mm)
- Contact Length - Post:-
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:-
- Mated Stacking Heights:4.5mm
- Ingress Protection:-
- Features:Board Guide, Solder Retention
- Current Rating (Amps):0.5A
- Voltage Rating:-
