NPTC291KFXC-RC
Sullins Connector Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 29POS 0.1 TIN SMD
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet NPTC291KFXC-RC Datasheet
-
ECAD Model
- Share
In Stock: 121
Can ship immediately
Pricing:
- 1$1.56992
- 1,000$1.56992
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- Connector Type:Header, Top or Bottom Entry
- Contact Type:Female Socket
- Style:Board to Board
- Number of Positions:29
- Number of Positions Loaded:All
- Pitch - Mating:0.100" (2.54mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Insulation Color:Black
- Insulation Height:0.280" (7.10mm)
- Contact Length - Post:-
- Operating Temperature:-40°C ~ 105°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:-
- Current Rating (Amps):3A
- Voltage Rating:250V
