DF11CZ-22DS-2V(52)
Hirose
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 22POS 0.079 GOLD SMD
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet DF11CZ-22DS-2V(52) Datasheet
-
ECAD Model
- Share
In Stock: 117
Can ship immediately
Pricing:
- 1$1.768
- 500$1.717
Quote It
Technical Details
- Series:DF11
- Package:Tape & Reel (TR)
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Female Socket
- Style:Board to Board or Cable
- Number of Positions:22
- Number of Positions Loaded:All
- Pitch - Mating:0.079" (2.00mm)
- Number of Rows:2
- Row Spacing - Mating:0.079" (2.00mm)
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:8.00µin (0.203µm)
- Insulation Color:Beige
- Insulation Height:0.234" (5.95mm)
- Contact Length - Post:-
- Operating Temperature:-30°C ~ 85°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:7.55mm, 8.2mm
- Ingress Protection:-
- Features:Pick and Place, Solder Retention
- Current Rating (Amps):2A
- Voltage Rating:250V
