FI-J40S-VF15N-R3000
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 40POS 0.016 GOLD SMD
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet FI-J40S-VF15N-R3000 Datasheet
-
ECAD Model
- Share
In Stock: 157
Can ship immediately
Pricing:
- 1$1.9656
- 3,000$1.9656
Quote It
Technical Details
- Series:FI-J
- Package:Tape & Reel (TR)
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Non-Gendered
- Style:Board to Cable/Wire
- Number of Positions:40
- Number of Positions Loaded:All
- Pitch - Mating:0.016" (0.40mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Surface Mount
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:3.90µin (0.099µm)
- Insulation Color:Black
- Insulation Height:0.046" (1.16mm)
- Contact Length - Post:-
- Operating Temperature:-40°C ~ 85°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Gold
- Mated Stacking Heights:1.58mm
- Ingress Protection:-
- Features:Pick and Place, Solder Retention
- Current Rating (Amps):0.3A per Contact
- Voltage Rating:50V
