DF3-12S-2DSA(55)
Hirose
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 12POS 0.079 GOLD PCB
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet DF3-12S-2DSA(55) Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
- 1$2.08222
- 18$1.96
Quote It
Technical Details
- Series:DF3
- Package:Tube
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Female Socket
- Style:Board to Board or Cable
- Number of Positions:12
- Number of Positions Loaded:All
- Pitch - Mating:0.079" (2.00mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:8.00µin (0.203µm)
- Insulation Color:Black
- Insulation Height:0.232" (5.90mm)
- Contact Length - Post:0.118" (3.00mm)
- Operating Temperature:-30°C ~ 85°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:6.6mm, 7.5mm
- Ingress Protection:-
- Features:-
- Current Rating (Amps):3A
- Voltage Rating:30VAC
