0022162256
Woodhead - Molex- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 25P 0.1 GOLD EDGE MNT
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet 0022162256 Datasheet
-
ECAD Model
- Share
In Stock: 129
Can ship immediately
Pricing:
- 1$2.53278
- 810$2.24332
Quote It
Technical Details
- Series:KK254, 4455
- Package:Tray
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Non-Gendered
- Style:Board to Board or Cable
- Number of Positions:25
- Number of Positions Loaded:All
- Pitch - Mating:0.100" (2.54mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Board Edge, Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Push-Pull
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:15.0µin (0.38µm)
- Insulation Color:White
- Insulation Height:0.185" (4.70mm)
- Contact Length - Post:0.132" (3.35mm)
- Operating Temperature:-40°C ~ 80°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:Board Hooks
- Current Rating (Amps):2.5A
- Voltage Rating:250VAC
