1-1586683-0
TE Connectivity AMP Connectors- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 15POS 0.25 TIN PCB
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet 1-1586683-0 Datasheet
-
ECAD Model
- Share
In Stock: 154
Can ship immediately
Pricing:
- 1$3.27135
- 200$3.11555
Quote It
Technical Details
- Series:Universal MATE-N-LOK
- Package:Bulk
- Part Status:Active
- Connector Type:Header
- Contact Type:Socket
- Style:Board to Cable/Wire
- Number of Positions:15
- Number of Positions Loaded:14
- Pitch - Mating:0.250" (6.35mm)
- Number of Rows:3
- Row Spacing - Mating:0.250" (6.35mm)
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Insulation Color:White
- Insulation Height:0.550" (13.97mm)
- Contact Length - Post:0.155" (3.94mm)
- Operating Temperature:-
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:-
- Current Rating (Amps):-
- Voltage Rating:-
