8-917570-7
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN HDR 7POS 0.059 GOLD SMD R/A
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet 8-917570-7 Datasheet
-
ECAD Model
- Share
In Stock: 166
Can ship immediately
Pricing:
- 1$4.7089
- 6,000$4.7089
Quote It
Technical Details
- Series:Mini VP
- Package:Tape & Reel (TR)
- Part Status:Active
- Connector Type:Header
- Contact Type:Female Blade Socket
- Style:Board to Cable/Wire
- Number of Positions:7
- Number of Positions Loaded:All
- Pitch - Mating:0.059" (1.50mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Surface Mount, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:8.00µin (0.203µm)
- Insulation Color:Black
- Insulation Height:0.128" (3.25mm)
- Contact Length - Post:-
- Operating Temperature:-40°C ~ 105°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Gold
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:-
- Current Rating (Amps):1A
- Voltage Rating:-
