009090095105805+
KYOCERA Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionWIRE TO BOARD
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$4.86
Quote It
Technical Details
- Series:9090, Kyocera
- Package:Bag
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Female Socket
- Style:Board to Cable/Wire
- Number of Positions:9
- Number of Positions Loaded:All
- Pitch - Mating:0.250" (6.35mm)
- Number of Rows:3
- Row Spacing - Mating:0.250" (6.35mm)
- Mounting Type:Through Hole
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Finish - Mating:Tin
- Contact Finish Thickness - Mating:-
- Insulation Color:-
- Insulation Height:0.551" (14.00mm)
- Contact Length - Post:0.146" (3.70mm)
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-2
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:-
- Current Rating (Amps):-
- Voltage Rating:600VAC
