SMS12SE5K9
Souriau-Sunbank by Eaton
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 12POS 0.2 GOLD PCB R/A
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$8.9725
- 100$8.9725
Quote It
Technical Details
- Series:SMS
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle
- Contact Type:Female Socket
- Style:Board to Board or Cable
- Number of Positions:12
- Number of Positions Loaded:All
- Pitch - Mating:0.200" (5.08mm)
- Number of Rows:4
- Row Spacing - Mating:0.200" (5.08mm)
- Mounting Type:Through Hole, Right Angle
- Termination:Solder
- Fastening Type:Locking Ramp
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:16.0µin (0.41µm)
- Insulation Color:Black
- Insulation Height:0.677" (17.20mm)
- Contact Length - Post:0.177" (4.50mm)
- Operating Temperature:-55°C ~ 105°C
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:IP40
- Features:Mounting Flange
- Current Rating (Amps):5A
- Voltage Rating:-
