M80-4051401

Technical Details

• Series:Datamate J-Tek
• Package:Tube
• Part Status:Active
• Connector Type:Receptacle
• Contact Type:Female Socket
• Style:Board to Board or Cable
• Number of Positions:14
• Number of Positions Loaded:All
• Pitch - Mating:0.079" (2.00mm)
• Number of Rows:2
• Row Spacing - Mating:0.079" (2.00mm)
• Mounting Type:Through Hole
• Termination:Solder
• Fastening Type:Screw Lock

• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:12.0µin (0.30µm)
• Insulation Color:Black
• Insulation Height:0.204" (5.17mm)
• Contact Length - Post:0.118" (3.00mm)
• Operating Temperature:-55°C ~ 125°C
• Material Flammability Rating:UL94 V-0
• Contact Finish - Post:Tin-Lead
• Mated Stacking Heights:7.3mm, 7.55mm
• Ingress Protection:-
• Features:Jackscrews, Mating Flange, Mounting Flange, Polarizing Key
• Current Rating (Amps):-
• Voltage Rating:800V
