FI-XPB30SRL-HF11
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT 30P 0.039 GOLD SMD R/A
- CategoryRectangular Connectors - Headers, Receptacles, Female Sockets
- Datasheet FI-XPB30SRL-HF11 Datasheet
-
ECAD Model
- Share
In Stock: 134
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:FI-XP
- Package:Tray
- Part Status:Obsolete
- Connector Type:Receptacle
- Contact Type:Non-Gendered
- Style:Board to Cable/Wire
- Number of Positions:30
- Number of Positions Loaded:All
- Pitch - Mating:0.039" (1.00mm)
- Number of Rows:1
- Row Spacing - Mating:-
- Mounting Type:Board Edge, Cutout; Bottom Mount, Surface Mount, Right Angle, Reverse Mount
- Termination:Solder
- Fastening Type:Friction Lock
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:12.0µin (0.30µm)
- Insulation Color:Black
- Insulation Height:-
- Contact Length - Post:-
- Operating Temperature:-
- Material Flammability Rating:UL94 V-0
- Contact Finish - Post:Tin
- Mated Stacking Heights:-
- Ingress Protection:-
- Features:Grounding Pins, Shielded, Solder Retention
- Current Rating (Amps):-
- Voltage Rating:-
