0009522138

Woodhead - Molex
In Stock: 138

Can ship immediately

Pricing:

Call for price or sumbit a RFQ

Quote It

Technical Details

  • Series:KK396, 2145
  • Package:Tray
  • Part Status:Obsolete
  • Connector Type:Receptacle, Bottom Entry
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:13
  • Number of Positions Loaded:All
  • Pitch - Mating:0.156" (3.96mm)
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Mounting Type:Through Hole
  • Termination:Solder
  • Fastening Type:Locking Ramp



  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:100.0µin (2.54µm)
  • Insulation Color:White
  • Insulation Height:0.449" (11.40mm)
  • Contact Length - Post:0.160" (4.06mm)
  • Operating Temperature:-40°C ~ 105°C
  • Material Flammability Rating:UL94 V-2
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:Board Hooks
  • Current Rating (Amps):4.5A
  • Voltage Rating:600V
