JN1DS04FK1
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG FMALE 4P SOLDER CUP
- CategoryCircular Connectors
- Datasheet JN1DS04FK1 Datasheet
-
ECAD Model
- Share
In Stock: 198
Can ship immediately
Pricing:
- 1$11.89
- 10$10.80909
- 25$10.53876
- 50$9.72818
- 100$9.18773
- 250$8.37707
- 500$7.83659
- 1,000$7.18805
Quote It
Technical Details
- Series:JN1
- Package:Bag
- Part Status:Active
- Connector Type:Plug, Female Sockets
- Number of Positions:4 (3 + PE)
- Shell Size - Insert:S
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Synthetic Resin
- Shell Finish:-
- Contact Finish - Mating:Silver
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Backshell, Coupling Nut
- Shielding:-
- Current Rating (Amps):5A
- Voltage Rating:200VAC
- Cable Opening:-
- Operating Temperature:-20°C ~ 125°C
