JN1AS10ML2-R
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MALE 10POS SOLDER CUP
- CategoryCircular Connectors
- Datasheet JN1AS10ML2-R Datasheet
-
ECAD Model
- Share
In Stock: 211
Can ship immediately
Pricing:
- 1$6.67
- 10$6.39208
- 25$5.83645
- 50$5.55833
- 100$5.28042
- 250$4.72458
- 500$4.44667
- 1,000$3.89083
- 2,500$3.69629
Quote It
Technical Details
- Series:JN1
- Package:Tray
- Part Status:Active
- Connector Type:Receptacle, Male Pins
- Number of Positions:10
- Shell Size - Insert:S
- Shell Size, MIL:-
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Termination:Solder Cup
- Fastening Type:Push-Twist
- Orientation:N (Normal)
- Shell Material:Synthetic Resin
- Shell Finish:-
- Contact Finish - Mating:Gold
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:-
- Shielding:-
- Current Rating (Amps):3A
- Voltage Rating:200VAC
- Cable Opening:-
- Operating Temperature:-20°C ~ 125°C
