JL04V-2E10SL-3PE-B-R
JAE Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN RCPT MALE 3P SOLDER CUP
- CategoryCircular Connectors
- Datasheet JL04V-2E10SL-3PE-B-R Datasheet
-
ECAD Model
- Share
In Stock: 238
Can ship immediately
Pricing:
- 1$12.25
- 10$11.14
- 25$10.8616
- 50$10.026
- 100$9.469
- 250$8.63352
- 500$8.0765
- 1,000$7.4081
Quote It
Technical Details
- Series:JL04V
- Package:Bulk
- Part Status:Active
- Connector Type:Receptacle, Male Pins
- Number of Positions:3 (2 + PE)
- Shell Size - Insert:10SL-3
- Shell Size, MIL:-
- Mounting Type:Panel Mount
- Mounting Feature:Flange
- Termination:Solder Cup
- Fastening Type:Threaded
- Orientation:N (Normal)
- Shell Material:Aluminum Alloy
- Shell Finish:Zinc
- Contact Finish - Mating:Silver
- Color:Black
- Ingress Protection:IP67 - Dust Tight, Waterproof
- Material Flammability Rating:-
- Features:Ground
- Shielding:-
- Current Rating (Amps):13A
- Voltage Rating:-
- Cable Opening:0.622" (15.80mm)
- Operating Temperature:-55°C ~ 125°C
