6282-2SG-516
Switchcraft / Conxall
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN PLUG FMALE 2P GOLD SLDR CUP
- CategoryCircular Connectors
- Datasheet 6282-2SG-516 Datasheet
-
ECAD Model
- Share
In Stock: 203
Can ship immediately
Pricing:
- 1$10.21
- 10$9.76609
- 25$8.87826
- 50$8.43435
- 100$8.21239
- 250$7.32457
- 500$6.88065
- 1,000$6.08161
Quote It
Technical Details
- Series:Mini-Con-X®
- Package:Bulk
- Part Status:Active
- Connector Type:Plug, Female Sockets
- Number of Positions:2
- Shell Size - Insert:-
- Shell Size, MIL:-
- Mounting Type:Free Hanging (In-Line)
- Mounting Feature:-
- Termination:Solder Cup
- Fastening Type:Bayonet Lock
- Orientation:Keyed
- Shell Material:Polyamide (PA), Nylon
- Shell Finish:-
- Contact Finish - Mating:Gold
- Color:Black
- Ingress Protection:Weathertight
- Material Flammability Rating:-
- Features:Backshell
- Shielding:Unshielded
- Current Rating (Amps):7.5A
- Voltage Rating:600V
- Cable Opening:0.160" ~ 0.180" (4.06mm ~ 4.57mm)
- Operating Temperature:-40°C ~ 115°C
